About this Product:
Anyone who wants to monitor a valuable item into a well, or off a
dock, or overboard will immediatly understand the signifigance of our
YVVL-KS-25A Underwater Camera. This high quality tool allows easy monitor
of underwater items, without the requirement for you to get wet or hire
an underwater diver. It works equally well under ice and most weather
conditions. It is a well designed and durably built addition to any Yacht
or Marine tool inventory.
1. Monitoring items from 30 to 100 meters underwater.
very small items (watches, phones, keys and purses) to very large items
(bicycles, pets and people) up to 80KGs in manual mode or up to a whopping
200kgs with winch assist.
2. Visual Fishing.
Put a stainless steel rod for the underwater robot just with camera, there is a hook on the end of the rod. Then you can put lure on it and can see from the LCD how the fish approach and get it!
for Crab, Shellfish etc.
3. Remotely exploring the sea bed, lake or river bottom.
a. Locate underwater Piping and Cable
b. Assist in freeing fouled Anchors and lines.
c. Virtually any underwater exploration.
4. Education and Fun for Young and Old
Visually explore everything from the water surface down to the
sea or lake bottom in vivid living color. Truly learn about the beautiful
coral, different kinds of fishes and plant life in Inner space!
The camera system is widely applied to aquaculture / underwater prospecting
/ underwater acceptance engineering / underwater activities / underwater
scientific research / diving expedition / deep sea archaeology / salvaging
/ catching / deep well relief / fishing and enjoy under the deep sea or
freshwater / fishing / yacht maintenance and etc.
Product Features And Description
Products can monitor from a depth of 30 to 100 meter underwater, incorporating
night vision with high definition and user-friendly CCD liquid –crystal
video display and water proof control switches.
Image Sensor：1/4\" SONY
Menus Show: OSD key with many languages.
User Friendly Lighting: 0Lux(when the high light and white light
are on ,the max current 360mA)
Rated Current: 70mA( if the red out light and white light )
Scanning System: 2:1nterlace
Signal-to-Noise Ratio (SNR) : ≥48Db
Automatic White Balance (AWB): On/Off
Video Out: 1.0Vp-p75Ω
Viewing Distance Underwater: 3 meters (normal sea conditions)
Lens : standard 3.6mm (choose)
Lens Angle : 92
Work Temperature: -20°C~+60°C
Cable: standard 30 meter, load-bearing 80kg
Protection Grad: IP68
Battery: Efficient 4.5AH battery / 8 hour monitor use and water
HD Monitor: 7in 800x480px protected with tempered glass.
Camera : Camera test to 1.0mpa or pressure rating up to a depth
1. One YVVL-KS-25A underwater camera monitor
2. One specification/operator’s manual
3. One storage battery
4. One battery charger
5. One luxury specification fight bump force toolbox
6. Standard 30 meters of Cable
